• NDT Laboratory

    Service offered:

      For health and condition assessment of concrete structures, Non-destructive evaluation techniques play an important role. Non-Destructive Testing Lab of NCCBM has a range of equipments to carry out Non-Destructive Testing and evaluation through techniques like Rebound Hammer Test, Ultrasonic Pulse Velocity test, Half-cell potential measurement, Rebar detection & concrete cover depth measurement, Concrete Core extraction, In-situ Carbonation depth measurement, Electrical Resistivity Test, Air permeability test, Crack width and crack depth measurement, Pull off Test on repair overlays, Measurement of Dry Film Thickness of coating using DFT meter, etc. These evaluation techniques are frequently made use of in quality and durability assessment as well as condition assessment of existing concrete structures. The laboratory has NABL accreditation as per ISO 17025-2017 for UPV Testing and Rebound Hammer testing

    Equipments and facilities available

      Ultrasonic Pulse Velocity (UPV) Tester for estimating quality of concrete, crack depth, etc

      Schmidt Rebound Hammers (L-Type, P-Type, N-Type & M-Type) for obtaining indicative measure of the compressive strength of concrete.

    • Half Cell Potential Measurement (Cu-CuSO4 based) for assessing the corrosion status of reinforcement bars
    • Concrete Cover Meter for locating reinforcement bars and measuring concrete cover depth
    • Concrete Core extraction kit with diamond core bits of various diameters (25mm, 60mm, 75mm, 100mm, 120mm, 300mm) for cutting and extracting concrete cores
    • Electrical Resistivity meter based on Wenner 4-probe method.
    • Air permeability tester.
    • Crack width measurement by portable crack width measurement microscope
    • Pull-Off tester
    • Coating thickness meter
    • Carbonation testing on concrete
    • CO2 Analyser
    Portable Core Drilling Kit N-Type Rebound Hammer Ultrasonic Pulse Velocity Testing Kit
    Half-Cell Potential Test Kit Air Permeability Test Kit Concrete cover measuring Equipment
    Electrical Resistivity Tester Pull Off Tester Dry Film Thickness Meter
